大数据离线数仓项目学习笔记

离线数仓项目

一、数据仓库概念

二、项目需求及架构设计

三、数据生成模块

3.1 服务器和 JDK 准备

3.1.1 配置IP、主机名

[jajiahao@hadoop102]$ vim /etc/sysconfig/network-scripts/ifcfg-ens33
[jajiahao@hadoop102]$ hostnamectl --static set-hostname hadoop102
[jajiahao@hadoop102]$ vim /etc/hosts
[jajiahao@hadoop102]$ vim /etc/sudoers(jajiahao  ALL=(ALL)   NOPASSWD:ALL)

3.1.2 编写集群分发脚本 xsync ，放到 /usr/local/bin 目录下

#!/bin/bash
#1 获取输入参数个数，如果没有参数，直接退出
pcount=$#
if((pcount==0)); then
echo no args;
exit;
fi

#2 获取文件名称
p1=$1
fname=`basename $p1`
echo fname=$fname

#3 获取上级目录到绝对路径
pdir=`cd -P $(dirname $p1); pwd`
echo pdir=$pdir

#4 获取当前用户名称
user=`whoami`

#5 循环
for((host=103; host<105; host++)); do
        echo ------------------- hadoop$host --------------
        rsync -rvl $pdir/$fname $user@hadoop$host:$pdir
done

修改执行权限

1	[jajiahao@hadoop102]$ chomd 777 xsync

3.1.3 配置 SSH 免密登录

在家目录创建 .ssh 文件，进入到 .ssh 目录下，生成公钥和私钥

1	[jajiahao@hadoop102]$ ssh-keygen -t rsa

将公钥拷贝到要免密登录的目标机器上

1
2
3

[jajiahao@hadoop102]$ ssh-copy-id hadoop102
[jajiahao@hadoop102]$ ssh-copy-id hadoop103
[jajiahao@hadoop102]$ ssh-copy-id hadoop104

在 hadoop102 上采用 jajiahao 账号配置一下免密登录到 hadoop102、hadoop103、hadoop104 服务器上

在 hadoop102 上采用 root 账号配置一下免密登录到 hadoop102、hadoop103、hadoop104 服务器上

在 hadoop103 上采用 jajiahao 账号配置一下免密登录到 hadoop102、hadoop103、hadoop104 服务器上

3.1.4 安装 JDK

1）卸载现有 JDK

1	[jajiahao@hadoop102 opt]$ sudo rpm -qa \| grep -i java \| xargs -n1 sudo rpm -e --nodeps -qa \| grep -i java

2）将 jdk 包放入 /opt/software 目录下，解压到 /opt/module 目录下

1	[jajiahao@hadoop102]$ tar -zxvf jdk-8u212-linux-x64.tar.gz -C /opt/module/

3）配置 JDK 环境变量，新建 /etc/profile.d/my_env.sh 文件

1	[jajiahao@hadoop102]$ sudo vim /etc/profile.d/my_env.sh

4）添加如下内容，保存退出（:wq）

1
2
3

#JAVA_HOME
export JAVA_HOME=/opt/module/jdk1.8.0_212
export PATH=$PATH:$JAVA_HOME/bin

5）让环境变量生效

1	[jajiahao@hadoop102]$ source /etc/profile.d/my_env.sh

6）测试 JDK 是否安装成功

1	[jajiahao@hadoop102]$ java -version

7）分发 JDK

1	[jajiahao@hadoop102]$ xsync /opt/module/jdk1.8.0_212

8）分发环境变量配置文件

1	[jajiahao@hadoop102]$ sudo xsync /etc/profile.d/my_env.sh

9）分别在hadoop103、hadoop104上执行 source

3.2 模拟数据

3.2.1 将本地的 application.properties、gmall2020-mock-log-2020-04-01.jar、path2.json 上传到 hadoop102 的 /opt/module/applog 目录下

3.2.2 配置 application.properties 文件，修改业务日期

3.2.3 在 /opt/module/applog 路径下执行日志生成命令

1	[jajiahao@hadoop102 applog]$ java -jar gmall2020-mock-log-2020-04-01.jar

3.2.4 在 /home/jajiahao/bin 目录下编写集群日志生成脚本 lg.sh

#!/bin/bash

for i in hadoop102 hadoop103
do
    echo "========== $i =========="
    ssh $i "cd /opt/module/applog/; java -jar gmall2020-mock-log-2020-04-01.jar >/dev/null 2>&1 &"
done

3.2.5 修改脚本执行权限：chmod 777 lg.sh

3.2.6 在 hadoop102 和 hadoop103 下执行脚本 lg.sh ，在 /opt/module/applog/log 目录下查看生成的数据

四、数据采集模块

4.1 集群所有进程查看脚本

1）新建脚本 xcall.sh

1	[jajiahao@hadoop102 bin]$ vim xcall.sh

2）脚本内容如下：

#! /bin/bash

for i in hadoop102 hadoop103 hadoop104
do
    echo --------- $i ----------
    ssh $i "$*"
done

3）修改脚本执行权限

1	[jajiahao@hadoop102 bin]$ chmod 777 xcall.sh

4）启动脚本

1	[jajiahao@hadoop102 bin]$ xcall.sh jps

4.2 Hadoop 安装部署

4.2.1 Hadoop安装

1）hadoop 3.1.3 安装配置环境变量，将文件解压到 /opt/module 目录下，修改 my_env.sh 文件

1	sudo vim /etc/profile.d/my_env.sh

2）添加如下内容

##HADOOP_HOME
export HADOOP_HOME=/opt/module/hadoop-3.1.3
export PATH=$PATH:$HADOOP_HOME/bin
export PATH=$PATH:$HADOOP_HOME/sbin

3）让配置文件生效

1	source /etc/profile.d/my_env.sh

4.2.2 配置集群

1）配置核心文件：core-site.xml

1 2	cd $HADOOP_HOME/etc/hadoop [jajiahao@hadoop102 hadoop]$ vim core-site.xml

文件内容如下

<configuration>
	<!-- 指定NameNode的地址 -->
    <property>
        <name>fs.defaultFS</name>
        <value>hdfs://hadoop102:9820</value>
</property>
<!-- 指定hadoop数据的存储目录 -->
    <property>
        <name>hadoop.tmp.dir</name>
        <value>/opt/module/hadoop-3.1.3/data</value>
</property>

<!-- 配置HDFS网页登录使用的静态用户为jajiahao -->
    <property>
        <name>hadoop.http.staticuser.user</name>
        <value>jajiahao</value>
</property>

<!-- 配置该jajiahao(superUser)允许通过代理访问的主机节点 -->
    <property>
        <name>hadoop.proxyuser.jajiahao.hosts</name>
        <value>*</value>
</property>
<!-- 配置该jajiahao(superUser)允许通过代理用户所属组 -->
    <property>
        <name>hadoop.proxyuser.jajiahao.groups</name>
        <value>*</value>
</property>
<!-- 配置该jajiahao(superUser)允许通过代理的用户-->
    <property>
        <name>hadoop.proxyuser.jajiahao.groups</name>
        <value>*</value>
</property>
</configuration>

2）HDFS 配置文件：hdfs-site.xml

1	[jajiahao@hadoop102 hadoop]$ vim hdfs-site.xml

文件内容如下：

<configuration>
	<!-- nn web端访问地址-->
	<property>
        <name>dfs.namenode.http-address</name>
        <value>hadoop102:9870</value>
    </property>

	<!-- 2nn web端访问地址-->
    <property>
        <name>dfs.namenode.secondary.http-address</name>
        <value>hadoop104:9868</value>
    </property>

    <!-- 测试环境指定HDFS副本的数量1 -->
    <property>
        <name>dfs.replication</name>
        <value>1</value>
    </property>
</configuration>

3）YARN 配置文件：yarn-site.xml

1	[jajiahao@hadoop102 hadoop]$ vim yarn-site.xml

文件内容如下：

<configuration>
	<!-- 指定MR走shuffle -->
    <property>
        <name>yarn.nodemanager.aux-services</name>
        <value>mapreduce_shuffle</value>
    </property>

    <!-- 指定ResourceManager的地址-->
    <property>
        <name>yarn.resourcemanager.hostname</name>
        <value>hadoop103</value>
    </property>

    <!-- 环境变量的继承 -->
    <property>
        <name>yarn.nodemanager.env-whitelist</name>
        <value>JAVA_HOME,HADOOP_COMMON_HOME,HADOOP_HDFS_HOME,HADOOP_CONF_DIR,CLASSPATH_PREPEND_DISTCACHE,HADOOP_YARN_HOME,HADOOP_MAPRED_HOME</value>
    </property>

    <!-- yarn容器允许分配的最大最小内存 -->
    <property>
        <name>yarn.scheduler.minimum-allocation-mb</name>
        <value>512</value>
    </property>
    <property>
        <name>yarn.scheduler.maximum-allocation-mb</name>
        <value>4096</value>
    </property>

    <!-- yarn容器允许管理的物理内存大小 -->
    <property>
        <name>yarn.nodemanager.resource.memory-mb</name>
        <value>4096</value>
    </property>

    <!-- 关闭yarn对物理内存和虚拟内存的限制检查 -->
    <property>
        <name>yarn.nodemanager.pmem-check-enabled</name>
        <value>false</value>
    </property>
    <property>
        <name>yarn.nodemanager.vmem-check-enabled</name>
        <value>false</value>
    </property>
</configuration>

4）MapReduce配置文件：mapred-site.xml

1	[jajiahao@hadoop102 hadoop]$ vim mapred-site.xml

文件内容如下：

<configuration>
	<!-- 指定MapReduce程序运行在Yarn上 -->
    <property>
        <name>mapreduce.framework.name</name>
        <value>yarn</value>
    </property>
</configuration>

5）配置 workers

1	[jajiahao@hadoop102 hadoop]$ vim workers

内容如下：

1
2
3

hadoop102
hadoop103
hadoop104

4.2.3 配置历史服务器

1）配置 mapred-site.xml，添加如下内容：

<!-- 历史服务器端地址 -->
<property>
	<name>mapreduce.jobhistory.address</name>
	<value>hadoop101:10020</value>
</property>

<!-- 历史服务器web端地址 -->
<property>
    <name>mapreduce.jobhistory.webapp.address</name>
    <value>hadoop101:19888</value>
</property>

4.2.4 配置日志的聚集，配置 yarn-site.xml ，增加以下内容：

<!-- 开启日志聚集功能 -->
<property>
    <name>yarn.log-aggregation-enable</name>
    <value>true</value>
</property>

<!-- 设置日志聚集服务器地址 -->
<property>
    <name>yarn.log.server.url</name>
    <value>http://hadoop102:19888/jobhistory/logs</value>
</property>

<!-- 设置日志保留时间为7天 -->
<property>
    <name>yarn.log-aggregation.retain-seconds</name>
    <value>604800</value>
</property>

4.2.5 分发 hadoop-3.1.3 、my_env.sh ，使用 source

1	[jajiahao@hadoop102 module]$ xsync hadoop-3.1.3/

4.2.6 启动 hadoop 集群

1）如果集群是第一次启动，需要在hadoop102节点格式化NameNode（注意格式化之前，一定要先停止上次启动的所有namenode和datanode进程，然后再删除data和log数据）

1 2	[jajiahao@hadoop102 hadoop-3.1.3]$ bin/hdfs namenode -format [jajiahao@hadoop102 hadoop-3.1.3]$ rm -rf data/ logs/

2) 启动 HDFS

1	[jajiahao@hadoop102 hadoop-3.1.3]$ sbin/start-dfs.sh

3) 在配置了ResourceManager的节点（hadoop103）启动YARN

1	[jajiahao@hadoop103 hadoop-3.1.3]$ sbin/start-yarn.sh

4) 查看是否启动

1	[jajiahao@hadoop102 hadoop-3.1.3]$ xcall.sh jps

4.2.7 Hadoop 群起脚本

1
2
3

[jajiahao@hadoop102 bin]$ pwd
/home/jajiahao/bin
[jajiahao@hadoop102 bin]$ vim hdp.sh

输入如下内容：

#!/bin/bash
if [ $# -lt 1 ]
then
    echo "No Args Input..."
    exit ;
fi
case $1 in
"start")
        echo " =================== 启动 hadoop集群 ==================="

        echo " --------------- 启动 hdfs ---------------"
        ssh hadoop102 "/opt/module/hadoop-3.1.3/sbin/start-dfs.sh"
        echo " --------------- 启动 yarn ---------------"
        ssh hadoop103 "/opt/module/hadoop-3.1.3/sbin/start-yarn.sh"
        echo " --------------- 启动 historyserver ---------------"
        ssh hadoop102 "/opt/module/hadoop-3.1.3/bin/mapred --daemon start historyserver"
;;
"stop")
        echo " =================== 关闭 hadoop集群 ==================="

        echo " --------------- 关闭 historyserver ---------------"
        ssh hadoop102 "/opt/module/hadoop-3.1.3/bin/mapred --daemon stop historyserver"
        echo " --------------- 关闭 yarn ---------------"
        ssh hadoop103 "/opt/module/hadoop-3.1.3/sbin/stop-yarn.sh"
        echo " --------------- 关闭 hdfs ---------------"
        ssh hadoop102 "/opt/module/hadoop-3.1.3/sbin/stop-dfs.sh"
;;
*)
    echo "Input Args Error..."
;;
esac

修改脚本权限

1	[jajiahao@hadoop102 bin]$ chmod 777 hdp.sh

测试脚本 hdp.sh

[jajiahao@hadoop102 bin]$ hdp.sh stop
 =================== 关闭 hadoop集群 ===================
 --------------- 关闭 historyserver ---------------
 --------------- 关闭 yarn ---------------
Stopping nodemanagers
Stopping resourcemanager
 --------------- 关闭 hdfs ---------------
Stopping namenodes on [hadoop102]
Stopping datanodes
Stopping secondary namenodes [hadoop104]

[jajiahao@hadoop102 bin]$ hdp.sh start
 =================== 启动 hadoop集群 ===================
 --------------- 启动 hdfs ---------------
Starting namenodes on [hadoop102]
Starting datanodes
Starting secondary namenodes [hadoop104]
 --------------- 启动 yarn ---------------
Starting resourcemanager
Starting nodemanagers
 --------------- 启动 historyserver ---------------

4.2.8 集群时间同步

4.2.9 LZO 压缩配置

# 将jar包移动到 common 目录下
[jajiahao@hadoop102 software]$ mv hadoop-lzo-0.4.20.jar /opt/module/hadoop-3.1.3/share/hadoop/common/
# 分发 jar 包
[jajiahao@hadoop102 common]$ xsync hadoop-lzo-0.4.20.jar

1）修改 core-site.xml 增加配置支持LZO压缩

<configuration>
    <property>
        <name>io.compression.codecs</name>
        <value>
            org.apache.hadoop.io.compress.GzipCodec,
            org.apache.hadoop.io.compress.DefaultCodec,
            org.apache.hadoop.io.compress.BZip2Codec,
            org.apache.hadoop.io.compress.SnappyCodec,
            com.hadoop.compression.lzo.LzoCodec,
            com.hadoop.compression.lzo.LzopCodec
        </value>
    </property>

    <property>
        <name>io.compression.codec.lzo.class</name>
        <value>com.hadoop.compression.lzo.LzoCodec</value>
    </property>
</configuration>

1 2	[jajiahao@hadoop102 hadoop]$ vim core-site.xml [jajiahao@hadoop102 hadoop]$ xsync core-site.xml

2）测试 LZO 压缩

# 测试数据准备
[jajiahao@hadoop102 ~]$ hadoop fs -mkdir /input
[jajiahao@hadoop102 hadoop-3.1.3]$ hadoop fs -put README.txt /input
# 测试
[jajiahao@hadoop102 hadoop-3.1.3]$ hadoop jar share/hadoop/mapreduce/hadoop-mapreduce-examples-3.1.3.jar wordcount -Dmapreduce.output.fileoutputformat.compress=true -Dmapreduce.output.fileoutputformat.codec=com.hadoop.compression.lzo.LzopCode /input /output

4.2.10 LZO 创建索引

1）创建LZO文件的索引，LZO压缩文件的可切片特性依赖于其索引，故我们需要手动为LZO压缩文件创建索引。若无索引，则LZO文件的切片只有一个。

2）测试

# 1. 将bigtable.lzo（200M）上传到集群的根目录
[jajiahao@hadoop102 module]$ hadoop fs -put bigtable.lzo /input
# 2. 执行wordcount程序
[jajiahao@hadoop102 module]$ hadoop jar /opt/module/hadoop-3.1.3/share/hadoop/mapreduce/hadoop-mapreduce-examples-3.1.3.jar wordcount -Dmapreduce.job.inputformat.class=com.hadoop.mapreduce.LzoTextInputFormat /input /output
# 3. 对上传的LZO文件建索引
[jajiahao@hadoop102 module]$ hadoop jar /opt/module/hadoop-3.1.3/share/hadoop/common/hadoop-lzo-0.4.20.jar  com.hadoop.compression.lzo.DistributedLzoIndexer /input/bigtable.lzo
# 4. 再次执行WordCount程序
[jajiahao@hadoop102 module]$ hadoop jar /opt/module/hadoop-3.1.3/share/hadoop/mapreduce/hadoop-mapreduce-examples-3.1.3.jar wordcount -Dmapreduce.job.inputformat.class=com.hadoop.mapreduce.LzoTextInputFormat /input /output2

4.2.11 基准测试

1）测试 HDFS 写性能

测试内容：向 HDFS 集群写 7（CPU核数 -1 ）个128M的文件

[jajiahao@hadoop102 module]$ hadoop jar /opt/module/hadoop-3.1.3/share/hadoop/mapreduce/hadoop-mapreduce-client-jobclient-3.1.3-tests.jar TestDFSIO -write -nrFiles 7 -fileSize 128MB
# 结果
2020-11-04 13:18:25,002 INFO fs.TestDFSIO: ----- TestDFSIO ----- : write
2020-11-04 13:18:25,002 INFO fs.TestDFSIO:             Date & time: Wed Nov 04 13:18:25 CST 2020
2020-11-04 13:18:25,002 INFO fs.TestDFSIO:         Number of files: 7
2020-11-04 13:18:25,002 INFO fs.TestDFSIO:  Total MBytes processed: 896
2020-11-04 13:18:25,002 INFO fs.TestDFSIO:       Throughput mb/sec: 44.51
2020-11-04 13:18:25,002 INFO fs.TestDFSIO:  Average IO rate mb/sec: 92.26
2020-11-04 13:18:25,002 INFO fs.TestDFSIO:   IO rate std deviation: 85.19
2020-11-04 13:18:25,002 INFO fs.TestDFSIO:      Test exec time sec: 22.63

注意：

Number of files：生成mapTask数量，一般是集群中CPU核数-1，我们测试虚拟机就按照实际的物理内存-1分配即可

Total MBytes processed：单个map处理的文件大小

Throughput mb/sec ：单个mapTak的吞吐量

计算方式：处理的总文件大小/每一个mapTask写数据的时间累加

集群整体吞吐量：生成mapTask数量*单个mapTak的吞吐量

Average IO rate mb/sec：单个mapTak的吞吐量

计算方式：每个mapTask处理文件大小/每一个mapTask写数据的时间累加/生成mapTask数量

IO rate std deviation：方差、反映各个mapTask处理的差值，越小越均衡

2）测试 HDFS 读性能

测试内容：读取 HDFS 集群7个128M的文件

[jajiahao@hadoop102 module]$ hadoop jar /opt/module/hadoop-3.1.3/share/hadoop/mapreduce/hadoop-mapreduce-client-jobclient-3.1.3-tests.jar TestDFSIO -read -nrFiles 7 -fileSize 128MB
# 结果
2020-11-04 13:27:31,475 INFO fs.TestDFSIO: ----- TestDFSIO ----- : read
2020-11-04 13:27:31,475 INFO fs.TestDFSIO:             Date & time: Wed Nov 04 13:27:31 CST 2020
2020-11-04 13:27:31,475 INFO fs.TestDFSIO:         Number of files: 7
2020-11-04 13:27:31,475 INFO fs.TestDFSIO:  Total MBytes processed: 896
2020-11-04 13:27:31,475 INFO fs.TestDFSIO:       Throughput mb/sec: 289.31
2020-11-04 13:27:31,475 INFO fs.TestDFSIO:  Average IO rate mb/sec: 415.26
2020-11-04 13:27:31,475 INFO fs.TestDFSIO:   IO rate std deviation: 289.65
2020-11-04 13:27:31,475 INFO fs.TestDFSIO:      Test exec time sec: 17.13

3）删除测试生成数据

1	[jajiahao@hadoop102 module]$ hadoop jar /opt/module/hadoop-3.1.3/share/hadoop/mapreduce/hadoop-mapreduce-client-jobclient-3.1.3-tests.jar TestDFSIO -clean

4.3 Zookeeper 安装

4.3.1 集群规划

在hadoop102、hadoop103和hadoop104三个节点上部署Zookeeper

4.3.2 解压安装

1）解压 Zookeeper安装包到 /opt/module/ 目录下

1	[jajiahao@hadoop102 software]$ tar -zxvf zookeeper-3.5.7.tar.gz -C /opt/module/

2）修改 /opt/module/apache-zookeeper-3.5.7-bin名称为zookeeper-3.5.7

1	[jajiahao@hadoop102 module]$ mv apache-zookeeper-3.5.7-bin/ zookeeper-3.5.7

3）分发 /opt/module/zookeeper-3.5.7 目录内容到 hadoop103、hadoop104

1	[jajiahao@hadoop102 module]$ xsync zookeeper-3.5.7/

4.3.3 ZK集群启动停止脚本

1）在hadoop102的/home/atguigu/bin目录下创建脚本

1	[jajiahao@hadoop102 bin]$ vim zk.sh

脚本内容如下：

#!/bin/bash

case $1 in
"start"){
	for i in hadoop102 hadoop103 hadoop104
	do
        echo ---------- zookeeper $i 启动 ------------
		ssh $i "/opt/module/zookeeper-3.5.7/bin/zkServer.sh start"
	done
};;
"stop"){
	for i in hadoop102 hadoop103 hadoop104
	do
        echo ---------- zookeeper $i 停止 ------------
		ssh $i "/opt/module/zookeeper-3.5.7/bin/zkServer.sh stop"
	done
};;
"status"){
	for i in hadoop102 hadoop103 hadoop104
	do
        echo ---------- zookeeper $i 状态 ------------
		ssh $i "/opt/module/zookeeper-3.5.7/bin/zkServer.sh status"
	done
};;
esac

2）增加脚本执行权限

1	[jajiahao@hadoop102 bin]$ chmod 777 zk.sh

3）脚本测试：

# 查看状态
[jajiahao@hadoop102 bin]$ zk.sh status
---------- zookeeper hadoop102 状态 ------------
ZooKeeper JMX enabled by default
Using config: /opt/module/zookeeper-3.5.7/bin/../conf/zoo.cfg
Client port found: 2181. Client address: localhost.
Mode: follower
---------- zookeeper hadoop103 状态 ------------
ZooKeeper JMX enabled by default
Using config: /opt/module/zookeeper-3.5.7/bin/../conf/zoo.cfg
Client port found: 2181. Client address: localhost.
Mode: leader
---------- zookeeper hadoop104 状态 ------------
ZooKeeper JMX enabled by default
Using config: /opt/module/zookeeper-3.5.7/bin/../conf/zoo.cfg
Client port found: 2181. Client address: localhost.
Mode: follower

# 集群停止
[jajiahao@hadoop102 bin]$ zk.sh stop
---------- zookeeper hadoop102 停止 ------------
ZooKeeper JMX enabled by default
Using config: /opt/module/zookeeper-3.5.7/bin/../conf/zoo.cfg
Stopping zookeeper ... STOPPED
---------- zookeeper hadoop103 停止 ------------
ZooKeeper JMX enabled by default
Using config: /opt/module/zookeeper-3.5.7/bin/../conf/zoo.cfg
Stopping zookeeper ... STOPPED
---------- zookeeper hadoop104 停止 ------------
ZooKeeper JMX enabled by default
Using config: /opt/module/zookeeper-3.5.7/bin/../conf/zoo.cfg
Stopping zookeeper ... STOPPED

# 集群启动
[jajiahao@hadoop102 bin]$ zk.sh start
---------- zookeeper hadoop102 启动 ------------
ZooKeeper JMX enabled by default
Using config: /opt/module/zookeeper-3.5.7/bin/../conf/zoo.cfg
Starting zookeeper ... STARTED
---------- zookeeper hadoop103 启动 ------------
ZooKeeper JMX enabled by default
Using config: /opt/module/zookeeper-3.5.7/bin/../conf/zoo.cfg
Starting zookeeper ... STARTED
---------- zookeeper hadoop104 启动 ------------
ZooKeeper JMX enabled by default
Using config: /opt/module/zookeeper-3.5.7/bin/../conf/zoo.cfg
Starting zookeeper ... STARTED

4.4 Kafka 安装部署

1）解压安装包

1	[jajiahao@hadoop102 software]$ tar -zxvf kafka_2.11-2.4.1.tgz -C /opt/module/

2）修改解压后的文件名称

1	[jajiahao@hadoop102 module]$ mv kafka_2.11-2.4.1/ kafka

3）在 /opt/module/kafka 目录下创建 logs 文件夹

1 2	[jajiahao@hadoop102 module]$ cd kafka/ [jajiahao@hadoop102 kafka]$ mkdir logs

4）修改配置文件

1 2	[jajiahao@hadoop102 kafka]$ cd config/ [jajiahao@hadoop102 config]$ vim server.properties

修改或者增加以下内容：

# broker 的全局唯一编号，不能重复
broker.id=0
# 删除topic功能使能
delete.topic.enable=true
# kafka运行日志存放的路径
log.dirs=/opt/module/kafka/data
# 配置连接Zookeeper集群地址
zookeeper.connect=hadoop102:2181,hadoop103:2181,hadoop104:2181/kafka

5）配置环境变量

1	[jajiahao@hadoop102 module]$ sudo vim /etc/profile.d/my_env.sh

添加如下内容：

1
2
3

#KAFKA_HOME
export KAFKA_HOME=/opt/module/kafka
export PATH=$PATH:$KAFKA_HOME/bin

让环境变量生效

1	[jajiahao@hadoop102 module]$ source /etc/profile.d/my_env.sh

6）分发安装包（注意：分发之后记得配置其他机器的环境变量）

1	[jajiahao@hadoop102 module]$ xsync kafka/

7）分别在hadoop103和hadoop104上修改配置文件 /opt/module/kafka/config/server.properties 中的 broker.id=1、broker.id=2

8）启动集群：依次在hadoop102、hadoop103、hadoop104节点上启动 kafka

1
2
3

[jajiahao@hadoop102 kafka]$ bin/kafka-server-start.sh -daemon /opt/module/kafka/config/server.properties
[jajiahao@hadoop103 kafka]$ bin/kafka-server-start.sh -daemon /opt/module/kafka/config/server.properties
[jajiahao@hadoop104 kafka]$ bin/kafka-server-start.sh -daemon /opt/module/kafka/config/server.properties

9）关闭集群

1
2
3

[jajiahao@hadoop102 kafka]$ bin/kafka-server-stop.sh
[jajiahao@hadoop103 kafka]$ bin/kafka-server-stop.sh
[jajiahao@hadoop104 kafka]$ bin/kafka-server-stop.sh

10）新建群起脚本，在 /home/jajiahao/bin 目录下创建脚本 kf.sh

1	[jajiahao@hadoop102 bin]$ vim kf.sh

脚本内容如下：

#!/bin/bash

case $1 in
"start"){
    for i in hadoop102 hadoop103 hadoop104
    do
        echo " --------启动 $i Kafka-------"
        ssh $i "/opt/module/kafka/bin/kafka-server-start.sh -daemon /opt/module/kafka/config/server.properties "
    done
};;
"stop"){
    for i in hadoop102 hadoop103 hadoop104
    do
        echo " --------停止 $i Kafka-------"
        ssh $i "/opt/module/kafka/bin/kafka-server-stop.sh stop"
    done
};;
esac

11）修改脚本执行权限

1	[jajiahao@hadoop102 bin]$ chmod 777 kf.sh

12）脚本测试

# kf集群脚本启动
[jajiahao@hadoop102 module]$ kf.sh start
# kf集群脚本停止
[jajiahao@hadoop102 module]$ kf.sh stop

13）Kafka 压力测试

1
2
3

[jajiahao@hadoop102 kafka]$ bin/kafka-producer-perf-test.sh  --topic test --record-size 100 --num-records 100000 --throughput -1 --producer-props bootstrap.servers=hadoop102:9092,hadoop103:9092,hadoop104:9092
# 结果
100000 records sent, 40933.278756 records/sec (3.90 MB/sec), 593.53 ms avg latency, 820.00 ms max latency, 633 ms 50th, 807 ms 95th, 817 ms 99th, 819 ms 99.9th.

14）Kafka Consumer 压力测试

1
2
3

[jajiahao@hadoop102 kafka]$ bin/kafka-consumer-perf-test.sh --broker-list hadoop102:9092,hadoop103:9092,hadoop104:9092 --topic test --fetch-size 10000 --messages 10000000 --threads 1
# 结果
2020-11-09 14:32:23:001, 2020-11-09 14:32:35:193, 9.5367, 0.7822, 100000, 8202.0997, 1604903543892, -1604903531700, -0.0000, -0.0001

测试结果说明：

1
2
3

start.time, end.time, data.consumed.in.MB, MB.sec, data.consumed.in.nMsg, nMsg.sec, rebalance.time.ms, fetch.time.ms, fetch.MB.sec, fetch.nMsg.sec
开始测试时间，测试结束时间，共消费数据9.5367MB，吞吐量0.7822MB/s，共消费100000条，平均每秒消费8202.0997条，
再平衡时间(ms)，fetch平均时间(ms)，fetch平均大小(MB/s)，fetch平均条数(条)

4.5 Flume 安装配置

4.5.1 Flume 安装

1）将 apache-flume-1.9.0-bin.tar.gz 上传到 linux 的 /opt/software 目录下

2）解压apache-flume-1.9.0-bin.tar.gz到/opt/module/目录下

1	[jajiahao@hadoop102 software]$ tar -zxvf apache-flume-1.9.0-bin.tar.gz -C /opt/module/

3）修改 apache-flume-1.9.0-bin 的名称为 flume

1	[jajiahao@hadoop102 module]$ mv apache-flume-1.9.0-bin/ flume

4）将lib文件夹下的guava-11.0.2.jar删除或修改以兼容Hadoop 3.1.3

1 2	[jajiahao@hadoop102 lib]$ mv guava-11.0.2.jar guava-11.0.2.jar.bak [jajiahao@hadoop102 lib]$ rm -rf guava-11.0.2.jar.bak

5）将 flume/conf 下的 flume-env.sh.template 文件修改为 flume-env.sh，并配置 flume-env.sh 文件

1 2	[jajiahao@hadoop102 conf]$ mv flume-env.sh.template flume-env.sh [jajiahao@hadoop102 conf]$ vim flume-env.sh

添加如下内容：

1	export JAVA_HOME=/opt/module/jdk1.8.0_212

6）分发flume

1	[jajiahao@hadoop102 module]$ xsync flume/

4.5.2 Flume 配置

1）在 /opt/module/flume/conf 目录下创建 file-flume-kafka.conf 文件

1	[jajiahao@hadoop102 conf]$ vim file_flume_kafka.conf

在文件配置如下内容：

# 为各组件命名
a1.sources = r1
a1.channels = c1

# 描述source
a1.sources.r1.type = TAILDIR
a1.sources.r1.filegroups = f1
a1.sources.r1.filegroups.f1 = /opt/module/applog/log/app.*
a1.sources.r1.positionFile = /opt/module/flume/taildir_position.json
a1.sources.r1.interceptors =  i1
a1.sources.r1.interceptors.i1.type = com.jajiahao.flume.interceptor.ETLInterceptor$Builder

# 描述channel
a1.channels.c1.type = org.apache.flume.channel.kafka.KafkaChannel
a1.channels.c1.kafka.bootstrap.servers = hadoop102:9092,hadoop103:9092
a1.channels.c1.kafka.topic = topic_log
a1.channels.c1.parseAsFlumeEvent = false

# 绑定source和channel以及sink和channel的关系
a1.sources.r1.channels = c1

注：com.atguigu.flume.interceptor.ETLInterceptor是自定义的拦截器的全类名，需要根据用户自定义的拦截器做相应修改

4.5.3 Flume 拦截器

1）创建Maven工程flume-interceptor

2) 创建包名：com.atguigu.flume.interceptor

3) 在pom.xml 文件中添加如下配置

<dependencies>
        <dependency>
            <groupId>org.apache.flume</groupId>
            <artifactId>flume-ng-core</artifactId>
            <version>1.9.0</version>
            <scope>provided</scope>
        </dependency>

        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>fastjson</artifactId>
            <version>1.2.62</version>
        </dependency>
    </dependencies>

    <build>
        <plugins>
            <plugin>
                <artifactId>maven-compiler-plugin</artifactId>
                <version>2.3.2</version>
                <configuration>
                    <source>1.8</source>
                    <target>1.8</target>
                </configuration>
            </plugin>
            <plugin>
                <artifactId>maven-assembly-plugin</artifactId>
                <configuration>
                    <descriptorRefs>
                        <descriptorRef>jar-with-dependencies</descriptorRef>
                    </descriptorRefs>
                </configuration>
                <executions>
                    <execution>
                        <id>make-assembly</id>
                        <phase>package</phase>
                        <goals>
                            <goal>single</goal>
                        </goals>
                    </execution>
                </executions>
            </plugin>
        </plugins>
    </build>

4）在com.atguigu.flume.interceptor包下创建 JSONUtils 类

package com.jajiahao.flume.interceptor;

import com.alibaba.fastjson.JSON;
import com.alibaba.fastjson.JSONException;

public class JSONUtils {
    public static boolean isValidate(String log) {
        try{
            JSON.parse(log);
            return true;
        }catch(JSONException e){
            return false;
        }
    }
}

5）在 com.atguigu.flume.interceptor 包下创建 ETLInterceptor 类

package com.jajiahao.flume.interceptor;

import org.apache.flume.Context;
import org.apache.flume.Event;
import org.apache.flume.interceptor.Interceptor;

import java.nio.charset.StandardCharsets;
import java.util.Iterator;
import java.util.List;

public class ETLInterceptor implements Interceptor {

    @Override
    public void initialize() {

    }

    @Override
    public Event intercept(Event event) {
        // 1. 获取数据
        byte[] body = event.getBody();
        String log = new String(body, StandardCharsets.UTF_8);
        // 2. 校验
        if(JSONUtils.isValidate(log)){
            return event;
        }
        return null;
    }

    @Override
    public List<Event> intercept(List<Event> list) {

        Iterator<Event> iterator = list.iterator();

        while(iterator.hasNext()){
            Event next = iterator.next();
            if(intercept(next)==null){
                iterator.remove();
            }
        }

        return list;
    }

    @Override
    public void close() {

    }

    public static class Builder implements Interceptor.Builder{

        @Override
        public Interceptor build() {
            return new ETLInterceptor();
        }

        @Override
        public void configure(Context context) {

        }
    }
}

6）打包得到 flume-interceptor-1.0-SNAPSHOT-jar-with-dependencies.jar 文件

7）将打好的包放入到 hadoop102 的 /opt/module/flume/lib 目录下

1 2	[jajiahao@hadoop102 lib]$ ls \| grep inter flume-interceptor-1.0-SNAPSHOT-jar-with-dependencies.jar

8）分发 jar包到hadoop103、hadoop104

1	[jajiahao@hadoop102 lib]$ xsync flume-interceptor-1.0-SNAPSHOT-jar-with-dependencies.jar

4.5.4 Flume 启动停止脚本

1）在/home/atguigu/bin目录下创建脚本 f1.sh

1	[jajiahao@hadoop102 bin]$ vim f1.sh

在脚本中填写如下内容：

#! /bin/bash

case $1 in
"start"){
        for i in hadoop102 hadoop103
        do
                echo " --------启动 $i 采集flume-------"
                ssh $i "nohup /opt/module/flume/bin/flume-ng agent --conf-file /opt/module/flume/conf/file-flume-kafka.conf --name a1 -Dflume.root.logger=INFO,LOGFILE >/opt/module/flume/log1.txt 2>&1  &"
        done
};;
"stop"){
        for i in hadoop102 hadoop103
        do
                echo " --------停止 $i 采集flume-------"
                ssh $i "ps -ef | grep file-flume-kafka | grep -v grep |awk  '{print \$2}' | xargs -n1 kill -9 "
        done

};;
esac

2）增加脚本执行权限

1	[jajiahao@hadoop102 bin]$ chmod 777 f1.sh

3）f1 集群启动脚本

1
2
3

[jajiahao@hadoop102 module]$ f1.sh start
 --------启动 hadoop102 采集flume-------
 --------启动 hadoop103 采集flume-------

4）f1 集群停止脚本

1	[jajiahao@hadoop102 module]$ f1.sh stop
